6-Axis Hexapod Tri-pod structer E-HEX-10.6.100.100-XXX Series Parallel six degrees of freedom stages

Short Description:

Features:
High precision, can be assembled, can be customized, light aperture 460mm

Delivers consistent and reliable motion accuracy in a compact and rugged stage
It has ultra-fine positioning resolution and sufficient payload capability
Ideal for applications requiring complex multi-degree of freedom motion when available space is limited. It is suitable for the leveling of semiconductor test wafer.
Application scenario of optical inspection, large hollow aperture adjustment optical path.

Send email to us

Product Detail

SPECIFICATION

Product Tags

Previous: HEX-S6.50.200 6-Axis Hexapod Tri-pod structer Parallel six degrees of freedom stages

Next: E-HEX-90.6.60.60 6-Axis Hexapod Tri-pod structer Parallel six degrees of freedom stages

Specification	XY	θXθY	Z	θZ
Travel	±50mm	±3deg	±50mm	±5deg
Motor type	Linear Motors	Linear Motors	Linear Motors	Direct drive motor
Opticval Encode resolution	4.88nm（1vpp）	4.88nm（1vpp）	4.88nm（1vpp）	0.04sec
Minimum step size	100nm	0.3sec	100nm	0.1sec
Repeatability	±0.2um	±1sec	±0.3um	±1sec
Positioning accuracy	±1um	-	±1um	±5sec
Maximum speed [mm/s]	100mm/s	30deg/sec	15mm/s	4rps
Maximum load [kg]	Horizontal load: 10kg, please contact the manufacturer for vertical load
Max mass	20kg
